Processor
• Dual AMD® EPYC™ 9005 and 9004 series Processors • Dual Socket SP5 (LGA6096)
Chipset
• None (AMD Turin PCH less architecture; all I/O provided by CPUs)
|
Memory
• 12+12 (24) DIMM slots Supports DDR5 RDIMM 12 Channel per CPU up to 6TB Capacity
• RDIMM/LRDIMM:max.6400MHz
Storage
• 2 x M.2-2280 PCIe x4 for NVMe for OS Boot Drives
• Optional 2 x SFF-8654 for (4) NVMe
|
Network
• 2 x 10Gbit RJ45 Intel® Ethernet Intel X550-AT2
Expansion Slot
• PCIe 5.0 6 HH HL x16, 1HH HL x8 [CPU1] [CPU2] (rear)
• Supports up to 7 RISER Slots
|
Graphics
• 1 x dedicated GLAN ASPEED AST2600: 1 DB15, 1 (15-pin header)
I/O
• 2 x USB 3.2 (Rear), 2 USB 3.2 (Front) • 2 x Serial Port (RJ45) • 1 x RJ45 IPMI 2.0 Port • 1 x DB15 VGA Port
|
Chassis
• 2U Rackmount with Front HDD LED • 6 x 2U Cooling Fans • Dimension: 3.43" H x 17.26" W x 25" D
Power Supply
• 2 x CRPS Hot Swap P/S 1+1 2000W Titanium Redundant
|
OS Support
• Windows Server, Linux, FreeBSD, VMware
Applications
• Virtual Server, Compute Server, Database Server, Cloud Computing
|
Environment
• System Operating Temperature: 0°C ~ 35°C (Please contact product specialist for details) • Non operating temperature: -20 to 70 C • Non-operating Relative Humidity: 5% to 85% (non-condensing)
|
