Processor
• Dual Intel® 6th Gen Xeon® Birch Stream-SP, up to 144 cores each, max 350W • Support 6700P, 6500P, 6700E series CPU
Chipset
• None (Intel Xeon 6 PCH‑less architecture; all I/O provided by CPUs) • Xeon-6 SoC
|
Memory
• 32 × DDR5 slots ((RDIMM/3DS RDIMM)，up to 6400MT/s, 16 channels • 6700P, 6500P series CPU support MRDIMMs, up to 8000MT/s
Storage
• 2 x M.2-2280/22110 for NVMe PCIe 5.0 x4 • 2 x Rear hotswap E1.S 9.5mm PCIe 5.0 x4 NVMe drive bays (CPU1)
|
Network
• 1 x PCIe 5.0 x16 OCP3 NIC mezzanine slot (CPU0, NCSI supported)
Expansion Slot
• 2 × PCIe 5.0 x16 FHFL double wide slots support max 400W PCIe card (1 from CPU0, 1 from CPU1) • 2 x PCIe 50 x16 FHFL single wide slots (1 from CPU0, 1 from CPU1) • 2 x PCIe 50 x16 FHHL single wide slots (1 from CPU0, 1 from CPU1)
|
I/O
Front I/O:
1 x USB 3.0 Type-A port
1 x USB 2.0 Type-A port
1 x System Power LED button
1 x UID LED button
1 x Reset button
4 x Status LEDs: Fault/LAN/M.2
Rear I/O:
2 x Hotswap E1S 95mm drive bays
1 x 1000BaseT Dedicated Server Management port
1 x COM USB Type A port
1 x USB 20 TypeA port
1 x Mini Display port
1 x Power LED (Green) button
1 x UID LED (Blue) button
1 x Status LEDs: Green/Red
|
Chassis
• 438mm (17.2") Wx 87mm (3.4") Hx 571mm (22.5")D
|
Power Supply
• 2 x 2000W CRPS 80PLUS Titanium
OS Support
• Windows Server, Linux, FreeBSD, VMware
|
Applications
• Cloud Computing Service • Content Delivery Network • AI Inference and Finetune
Environment
• System Operating Temperature: 0°C ~ 35°C • Non-operating Temperature: -20°C ~ 70°C • Non-operating Relative Humidity: 5% to 85% (non-condensing)
|
